7
Icons
172
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
7.8 Special symbols for large dialog windows
'Set' button
For final setting when selecting / entering an element category / address in the
element search dialog window or function dialog window:
normal pressed disabled
Symbol for 'Set' button
Substructure symbol in topology dialog window
Substructure symbol topology dialog window
Symbols in large options list
'Processing
state'
Large options list
All In event memory In topology
Select check
mark
1
Local station Faulty station Root Subpath
normal ---
pressed ---
selected --- --- --- --- ---
disabled --- --- --- ---
Symbols in large options list
1
Differs from 'Gone' processing symbol in the shape of the check mark.
