7.7 Special symbols for main dialog window
'Unacknowledged' symbols for list tabs (LT) / system tabs (ST)
Star for 'Unacknowledged' events in buttons on list tabs / system tabs
Button
'normal' 'selected'
'Unacknowledged' symbol for list tabs / system tabs
Symbols, indicator for command execution (ICE)
Quiescent
condition
Waiting
Waiting / n of m
command OK
Waiting / n of m
command not
OK
Command OK
Command not
OK
Static Animated Static
Indicator for command execution
'Logo in idle view (system normal screen)'
Idle view
