5
Operation
Activation / Deactivation / Reset
128
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
5.5.4 Activating / deactivating fire control
Activating a 'Fire control'
w You are logged onto at least 'Access level' 2.1.
w You are in the 'Topology' dialog window.
1. Press 'Lower level' in the 'Control tree' list entry.
a All 'Stations' in the 'Control tree' are displayed.
2. Press 'Lower level' in an 'Station' list entry.
a All elements of the 'Station' are displayed.
3. Select 'Fire gr' 1.
a The highlighted list entry is displayed with a bright background.
4. Press 'Execute commands' on the dialog window toolbar.
a The 'Select command' dialog window opens.
5. Select the 'Activate' command.
a The command execution display confirms successful execution of the
command by displaying .
a 'Fire control' is activated.
Deactivating a 'Fire control'
1. Repeat steps 1 - 4 of the instruction 'Activate a'Fire control''.
a The 'Select command' dialog window opens.
2. Select the 'Deactivate' command.
a The command execution display confirms successful execution of the
command by displaying .
a 'Fire control' is deactivated.
