5
Operation
152
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
4. Select a setting.
a The command execution display confirms successful execution of the
command by displaying .
a The touch screen brightness has been set.
5.9.5 Setting the buzzer volume
You can set the sound level of the ↑ 'Station' buzzer on four levels or switch it off.
NOTICE
Non-compliance with EN 54-2 Para 12.10.2
Set the buzzer sound level to the maximum.
As per EN 54-2, the minimum sound level at a distance of 1 m must reach the
following values, measured under open air conditions:
-60 dB (A) for announcing fire alarm signals
-50 dB (A) for announcing fault messages
'Set buzzer volume'
w You are logged onto 'Access level' 2.2.
w You are in 'Main menu'.
1. Select the 'Settings/administration' menu item.
a The 'Settings/administration' menu is displayed.
