Operation
5
131
Building Technologies A6V10380629_en--_a
Fire Safety 2015-09-10
a All 'Areas' in the 'Detection tree' are displayed.
3. Press 'Lower level' in the list entry for 'Station'.
a The elements of 'Station' are displayed.
4. Press 'Lower level' in the 'PMI' list entry.
a The elements of the 'PMI' are displayed.
5. Select 'PMI exp'.
a The highlighted list entry is displayed in color.
6. Press 'Execute commands' on the dialog window toolbar.
a The 'Select command' dialog window opens.
7. Select the 'Activate expanded visibility' command.
a The command execution display confirms successful execution of the
command by displaying .
a The 'Expanded visibility' is activated.
Deactivating the 'Expanded visibility' function
w You are logged onto at least 'Access level' 2.1.
1. Press the 'System messages' tab.
