3 Functions Issue 07/04
MICROMASTER 420 Operating Instructions
68 6SE6400-5AA00-0BP0
Table 3-8 Example 1LA7060-4AB10
Delta circuit
configuration
87 Hz
characteristic
Star circuit
configuration
P0304 Rated motor voltage 230 V 400 V 400 V
P0305 Rated motor current 0.73 A 0.73 A 0.42 A
P0307 Rated motor power 120 W 207 W 120 W
P0308
Cos
ϕ
0.75 0.75 0.75
P0310 Rated motor frequency 50 Hz 87 Hz 50 Hz
P0311 Rated motor speed 1350 RPM 2460 RPM 1350 RPM
P0314 Motor pole pairs 2 2 2
Contrary to the BOP, AOP operator panels or commissioning tool program
DriveMonitor, the STARTER commissioning (start-up) program offers a mask-
orientated quick commissioning, which is especially advantageous for users who
are using MICROMASTER for the first time. On the other hand, BOP, AOP and
DriveMonitor offer, in conjunction with the drive inverter, parameter-orientated
quick commissioning where the user is navigated through the menu tree mentioned
above.
NOTE
The MICROMASTER series of drive units is not available for 3-ph. 690 V AC.
