3 Commissioning
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
41
NOTES
In some cases - when changing parameter values - the display on the BOP-2
shows
. This means the inverter is busy with tasks of higher priority.
Changing single digits in Parameter values
For changing the parameter value rapidly, the single digits of the display can be
changed by performing the following actions:
Ensure you are in the parameter value changing level (see "Changing parameters
with BOP-2").
1. Press
(function button), which causes the right hand digit to blink.
2. Change the value of this digit by pressing
/ .
3. Press
(function button) again causes the next digit to blink.
4. Perform steps 2 to 4 until the required value is displayed.
5. Press the
to leave the parameter value changing level.
NOTES
The function button may also be used to acknowledge a fault condition
3.2.3 Commissioning functions with BOP-2
3.2.3.1 Quick commissioning (P0010=1)
Mechanical and electrical installation of the inverter must be completed before
running „Quick Commissioning“.
It is important that parameter P0010 is used for commissioning and P0003 is used
to select the access level.
There are three user levels, standard, extended and expert. The lower the access
level fewer parameters can be seen while performing Quick commissioning. The
values for these parameters are either the default settings or are calculated during
quick commissioning.
Quick commissioning includes motor and ramp setting parameters.
Quick Commissioning concludes with P3900, which, when set to 1, will perform the
necessary motor calculations and clear all other parameters (not included in
P0010=1) to the default settings. After completing Quick Commissioning with
P3900 = 1, the inverter is then ready to run; this will only happen in the Quick
Commissioning mode.
