Siemens MICROMASTER 430 Manual

3 Commissioning
MICROMASTER 430 Operating Instructions
42 6SE6400-5AC00-0BP0
Flow chart Quick Commissioning
P0010 Start Quick Commissioning
2)
0 Ready to Run
1 Ready to Run
30 Factory Setting
P0100 Operation for Europe/N. America
0 Power in kW; f default 50 Hz
1 Power in hp; f default 60 Hz
2 Power in kW; f default 60 Hz
NOTE
Settings 0 and 1 should be changed using the DIP
switches to allow permanent setting. The DIP
switches should be used to create permanent
settings. After a mains break the DIP switch settings
overide the parameter settings.
P0205 Inverter application
0 Constant torque
1 Variable torque
Note
For FS A, FS B and single phase FS C inverters only
P0205 = 0 is available.
P0205 = 1 should only be used in applications with
quadratic characteristic (pumps, fans)
P0300 Select motor type
1 Asynchronous rotational motor
2 Synchronous rotational motor
Note
With P0300 = 2 the control parameters are disabled
P0304 Rated Motor Voltage
1)
Setting range: 10 V - 2000 V
Nominal motor voltage (V) from rating plate.
P0307 Rated Motor Power
1)
Setting range: 0,01 kW - 2000 kW
Nominal motor power (kW) from rating plate.
If P0100 = 1, values will be in hp.
P0308 Rated motor cosPhi
1)
Setting range: 0,000 - 1,000
Nom. motor power factor (cosPhi) from rating plate .
Visible only when P0100 = 0, 2, (motor power in kW).
P0309 Rated motor efficiency
1)
Setting range: 0,0 - 99,9 %
Nominal motor efficiency in % from rating plate. .
Visible only when P0100 = 1, ( motor power in hp).
P0310 Rated Motor Frequency
1)
Setting range: 12 Hz - 650 Hz
Nominal motor frequency (Hz) from rating plate.
P0311 Rated Motor Speed
1)
Setting range: 0 - 40.000 U/min
Nominal motor speed (rpm) from rating plate.
P0320 Motor magnetizing current
Setting range: 0.0 - 99.0 %
Motor magnetizing current (%) relative to the rated
motor current (P0305).
P0335 Motor cooling
0 Self-cooled
1 Force-cooled
2 Self-cooled and internal fan
3 Force-cooled and internal fan
P0640 Motor overload factor
Setting range: 10.0 - 400.0 %
Motor overload current limit [%] relative to P0305
(rated motor current).
1
Access level
1
3
2
1
2
P0305 Rated Motor Current
1)
Setting range: 0 - 2 x inverter rated current (A)
Nominal motor current (A) from rating plate.
1
2
3
1
1
2
2
1
P0700 Selection of Command Source
2)
0 Factory Setting
1BOP-2
2 Terminals (Digital Inputs)
1
Note
If P0700 = 2 is selected, the function of the digital
inputs can be determind via P0701 to P0708. P0701
to P0708 = 99 enables the BICO-parameterization for
the digital inputs.
P0003 User access level
2)
1 Standard
2 Extended
3 Expert
1
1)
Motor-specific parameters – see motor rating plate.
2)
The parameters offer more setting options than listed here. See Parameter List for further setting
options.
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
