Siemens MICROMASTER 430 Manual

5 System parameters
MICROMASTER 430 Operating Instructions
70 6SE6400-5AC00-0BP0
ParNr ParText Default Level DS QC
P2216 Fixed PID setpoint mode - Bit 0 1 3 CT N
P2217 Fixed PID setpoint mode - Bit 1 1 3 CT N
P2218 Fixed PID setpoint mode - Bit 2 1 3 CT N
P2219 Fixed PID setpoint mode - Bit 3 1 3 CT N
r2224 CO: Act. fixed PID setpoint - 3 - -
P2225 Fixed PID setpoint mode - Bit 4 1 3 CT N
P2227 Fixed PID setpoint mode - Bit 5 1 3 CT N
P2232 Inhibit rev. direct. of PID-MOP 1 3 CT N
P2231[3] Setpoint memory of PID-MOP 1 3 CUT N
P2240[3] Setpoint of PID-MOP 10.00 3 CUT N
r2250 CO: Output setpoint of PID-MOP - 3 - -
P2255 PID setpoint gain factor 100.00 3 CUT N
P2253[3] CI: PID setpoint 2250:0 2 CUT N
P2256 PID trim gain factor 100.00 3 CUT N
P2257 Ramp-up time for PID setpoint 1.00 2 CUT N
P2254[3] CI: PID trim source 0:0 3 CUT N
P2258 Ramp-down time for PID setpoint 1.00 2 CUT N
r2260 CO: PID setpoint after PID-RFG - 2 - -
P2261 PID setpoint filter timeconstant 0.00 3 CUT N
r2262 CO: Filtered PID setp. after RFG - 3 - -
P2263 PID controller type 0 3 T N
P2265 PID feedback filter timeconstant 0.00 2 CUT N
r2266 CO: PID filtered feedback - 2 - -
P2264[3] CI: PID feedback 755:1 2 CUT N
P2267 Max. value for PID feedback 100.00 3 CUT N
P2268 Min. value for PID feedback 0.00 3 CUT N
P2269 Gain applied to PID feedback 100.00 3 CUT N
P2270 PID feedback function selector 0 3 CUT N
P2271 PID transducer type 0 2 CUT N
r2272 CO: PID scaled feedback - 2 - -
r2273 CO: PID error - 2 - -
P2274 PID derivative time 0.000 2 CUT N
P2280 PID proportional gain 3.000 2 CUT N
P2285 PID integral time 0.000 2 CUT N
P2291 PID output upper limit 100.00 2 CUT N
P2292 PID output lower limit 0.00 2 CUT N
P2293 Ramp-up /-down time of PID limit 1.00 3 CUT N
r2294 CO: Act. PID output - 2 - -
P2370[3] Motor staging stop mode 0 3 CT N
P2371[3] External motor configuration 0 3 CT N
P2372[3] Enable motor cycling 0 3 CT N
P2373[3] Motor staging hysteresis 20.0 3 CUT N
P2374[3] Motor staging delay 30 3 CUT N
P2375[3] Motor destaging delay 30 3 CUT N
P2376[3] Delay override 25.0 3 CUT N
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
