5 System parameters
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
69
ParNr ParText Default Level DS QC
P2167[3] Switch-off frequency f_off 1.00 3 CUT N
P2168[3] Delay time T_off 10 3 CUT N
r2169 CO: Act. Filtered frequency - 3 - -
P2170[3] Threshold current I_thresh 100.0 3 CUT N
P2171[3] Delay time current 10 3 CUT N
P2172[3] Threshold DC-link voltage 800 3 CUT N
P2173[3] Delay time DC-link voltage 10 3 CUT N
P2174[3] Torque threshold T_thresh 5.13 3 CUT N
P2176[3] Delay time for torque threshold 10 3 CUT N
P2177[3] Delay time for motor is blocked 10 3 CUT N
P2178[3] Delay time for motor pulled out 10 3 CUT N
P2179 Current limit for no load ident. 3.0 3 CUT N
P2180 Delay time for no load ident. 2000 3 CUT N
P2181[3] Belt failure detection mode 0 3 CT N
P2182[3] Belt threshold frequency 1 5.00 3 CUT N
P2183[3] Belt threshold frequency 2 30.00 3 CUT N
P2184[3] Belt threshold frequency 3 50.00 3 CUT N
P2185[3] Upper torque threshold 1 99999.0 3 CUT N
P2186[3] Lower torque threshold 1 0.0 3 CUT N
P2187[3] Upper torque threshold 2 99999.0 3 CUT N
P2188[3] Lower torque threshold 2 0.0 3 CUT N
P2189[3] Upper torque threshold 3 99999.0 3 CUT N
P2190[3] Lower torque threshold 3 0.0 3 CUT N
P2192[3] Time delay for belt failure 10 3 CUT N
r2197 CO/BO: Monitoring word 1 - 3 - -
r2198 CO/BO: Monitoring word 2 - 3 - -
PI Controller (P0004 = 22)
ParNr ParText Default Level DS QC
P2200[3] BI: Enable PID controller 0:0 2 CUT N
P2201[3] Fixed PID setpoint 1 0.00 3 CUT N
P2202[3] Fixed PID setpoint 2 10.00 3 CUT N
P2203[3] Fixed PID setpoint 3 20.00 3 CUT N
P2204[3] Fixed PID setpoint 4 30.00 3 CUT N
P2205[3] Fixed PID setpoint 5 40.00 3 CUT N
P2206[3] Fixed PID setpoint 6 50.00 3 CUT N
P2207[3] Fixed PID setpoint 7 60.00 3 CUT N
P2208[3] Fixed PID setpoint 8 70.00 3 CUT N
P2209[3] Fixed PID setpoint 9 80.00 3 CUT N
P2210[3] Fixed PID setpoint 10 90.00 3 CUT N
P2211[3] Fixed PID setpoint 11 100.00 3 CUT N
P2212[3] Fixed PID setpoint 12 110.00 3 CUT N
P2213[3] Fixed PID setpoint 13 120.00 3 CUT N
P2214[3] Fixed PID setpoint 14 130.00 3 CUT N
P2215[3] Fixed PID setpoint 15 130.00 3 CUT N
