Siemens MICROMASTER 430 Manual

5 System parameters
MICROMASTER 430 Operating Instructions
68 6SE6400-5AC00-0BP0
ParNr ParText Default Level DS QC
r2028[2] USS parity error - 3 - -
r2029[2] USS start not identified - 3 - -
r2030[2] USS BCC error - 3 - -
r2032 BO: CtrlWrd1 from BOP link (USS) - 3 - -
r2031[2] USS length error - 3 - -
r2033 BO: CtrlWrd2 from BOP link (USS) - 3 - -
r2036 BO: CtrlWrd1 from COM link (USS) - 3 - -
r2037 BO: CtrlWrd2 from COM link (USS) - 3 - -
P2040 CB telegram off time 20 3 CT N
P2041[5] CB parameter 0 3 CT N
r2050[8] CO: PZD from CB - 3 - -
r2053[5] CB identification - 3 - -
P2051[8] CI: PZD to CB 52:0 3 CT N
r2054[7] CB diagnosis - 3 - -
r2090 BO: Control word 1 from CB - 3 - -
r2091 BO: Control word 2 from CB - 3 - -
Alarms, Warnings and Monitoring (P0004 = 21)
ParNr ParText Default Level DS QC
r0947[8] Last fault code - 3 - -
r0948[12] Fault time - 3 - -
r0949[8] Fault value - 3 - -
P0952 Total number of faults 0 3 CT N
P2100[3] Alarm number selection 0 3 CT N
P2101[3] Stop reaction value 0 3 CT N
r2110[4] Warning number - 3 - -
P2111 Total number of warnings 0 3 CT N
r2114[2] Run time counter - 3 - -
P2115[3] AOP real time clock 0 3 CT N
P2150[3] Hysteresis frequency f_hys 3.00 3 CUT N
P2151[3] CI: Monitoring speed setpoint 0:0 3 CUT N
P2152[3] CI: Act. Monitoring speed 0:0 3 CUT N
P2153[3] Time-constant speed filter 5 3 CUT N
P2155[3] Threshold frequency f_1 30.00 3 CUT N
P2156[3] Delay time of threshold freq f_1 10 3 CUT N
P2157[3] Threshold frequency f_2 30.00 3 CUT N
P2158[3] Delay time of threshold freq f_2 10 3 CUT N
P2159[3] Threshold frequency f_3 30.00 3 CUT N
P2160[3] Delay time of threshold freq f_3 10 3 CUT N
P2161[3] Min. threshold for freq. Setp. 3.00 3 CUT N
P2162[3] Hysteresis freq. For overspeed 20.00 3 CUT N
P2163[3] Entry freq. For perm. Deviation 3.00 3 CUT N
P2164[3] Hysteresis frequency deviation 3.00 3 CUT N
P2165[3] Delay time permitted deviation 10 3 CUT N
P2166[3] Delay time ramp up completed 10 3 CUT N
