Siemens MICROMASTER 430 Manual

7 MICROMASTER 430 specifications
MICROMASTER 430 Operating Instructions
88 6SE6400-5AC00-0BP0
Input voltage range 3 AC 380 V – 480 V, ± 10 %
(with built in Class A Filter), Part 2
Order No. 6SE6430-
2AD33-
0DA0
2AD33-
7EA0
2AD34-
5EA0
2AD35-
5FA0
2AD37-
5FA0
2AD38-
8FAO
[kW]
30.0 37.0 45.0 55.0 75.0 90.0
Motor Output Rating
[hp]
40.0 50.0 60.0 75.0 100.0 120.0
Output Power [kVA]
34.3 47.3 57.2 68.6 83.8 110.5
VT Input Current [A]
59.3 71.7 86.6 103.6 138.5 168.5
VT Output Cur. Max. [A]
62.0 75.0 90.0 110.0 145.0 178.0
80 100 125 160 160 200
Recommended Fuse [A]
3NA3024 3NA3030 3NA3032 3NA3036 3NA3036 3NA3140
[A]
80 100 125 160 200 200
Fuses recomnended
for UL applications
3NE
1820-0 1021-0 1022-0 1224-0 1225-0 1225-0
[mm
2
] 16.0 25.0 25.0 35.0 70.0 70.0
Input Cable Min.
[awg]
5332-2-2
[mm
2
]
35.0 35.0 35.0 150.0 150.0 150.0
Input Cable Max.
[awg]
2 2 2 -5 -5 -5
[mm
2
]
16.0 25.0 25.0 50.0 70.0 95.0
Output Cable Min.
[awg]
5330-2-3
[mm
2
] 35.0 35.0 35.0 150.0 150.0 150.0
Output Cable Max.
[awg]
2 2 2 -5 -5 -5
[kg]
17.0 22.0 22.0 75.0 75.0 75.0
Weight
[lbs]
37.0 48.0 48.0 165.0 165.0 165.0
w [mm]
275.0 275.0 275.0 350.0 350.0 350.0
h [mm]
520.0 650.0 650.0 1150.0 1150.0 1150.0
d [mm]
245.0 245.0 245.0 320.0 320.0 320.0
w [inches] 10.83 10.83 10.83 13.78 13.78 13.78
h [inches]
20.47 25.59 25.59 45.28 45.28 45.28
Dimensions
d [inches]
9.65 9.65 9.65 12.6 12.6 12.6
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
