Siemens MICROMASTER 430 Manual

7 MICROMASTER 430 specifications
MICROMASTER 430 Operating Instructions
6SE6400-5AC00-0BP0
89
Input voltage range 3 AC 380 V – 480 V, ± 10 % (Unfiltered), Part 1
Order No.
6SE6430
-
2UD27-
5CA0
2UD31-
1CA0
2UD31-
5CA0
2UD31-
8DA0
2UD32-
2DA0
[kW]
7.5 11.0 15.0 18.5 22.0
Motor Output Rating
[hp]
10.0 15.0 20.0 25.0 30.0
Output Power [kVA]
10.1 14.0 19.8 24.4 29.0
VT Input Current [A]
16.0 22.5 30.5 37.2 43.3
VT Output Cur. Max. [A]
18.4 26.0 32.0 38.0 45.0
20 32 35 50 63
Recommended Fuse [A]
3NA3007 3NA3012 3NA3014 3NA3020 3NA3022
[A]
50 63
Fuses recomnended
for UL applications
3NE
1817-0 1818-0
[mm
2
]
2.5 4.0 6.0 10.0 10.0
Input Cable Min.
[awg]
13 11 9 7 7
[mm
2
]
10.0 10.0 10.0 35.0 35.0
Input Cable Max.
[awg]
77722
[mm
2
] 2.5 4.0 6.0 10.0 10.0
Output Cable Min.
[awg]
13 11 9 7 7
[mm
2
]
10.0 10.0 10.0 35.0 35.0
Output Cable Max.
[awg]
77722
[kg]
5.5 5.5 5.5 16.0 16.0
Weight
[lbs]
12.1 12.1 12.1 35.0 35.0
w [mm]
185.0 185.0 185.0 275.0 275.0
h [mm]
245.0 245.0 245.0 520.0 520.0
d [mm]
195.0 195.0 195.0 245.0 245.0
w [inches]
7.28 7.28 7.28 10.83 10.83
h [inches]
9.65 9.65 9.65 20.47 20.47
Dimensions
d [inches]
7.68 7.68 7.68 9.65 9.65
www.eltra-trade.com
+421 552 601 099
info@eltra-trade.com

Siemens MICROMASTER 430 Specifications

General

Power Range	7.5 kW to 250 kW
Voltage Range	380V to 480V
Frequency Range	0 Hz to 650 Hz
Protection Class	IP20
Input Frequency	47 Hz to 63 Hz
Digital Inputs	6
Cooling Method	Forced-air cooling
Communication	USS
Protection Features	Overvoltage, undervoltage, overcurrent, short-circuit, ground fault, overtemperature
Analog Inputs	2
Digital Outputs	3
Analog Outputs	2
Ambient Temperature	-10°C to +50°C
Control Type	Sensorless vector control
