Siemens MOBILETT Plus HP Service Manual

Mechanical systems 10 - 15
Siemens AG SPR8-220.061.03 Page 15 of 28 MOBILETT Plus HP
Medical Solutions Rev. 03 09.03 CS PS 24
• Reconnect all electrical connections according to Fig. 18.
• Install the collimator and replace the cable ties according to the information in chapter 9.
• Tighten the adjustment screw (Fig. 16) so that the single tank is balanced.
• Set switch S10 in the OFF position.
Fig. 18
MOB00651
BK = Black
BU = Blue
RD = Red
YE = Yellow
GN/YE = Green/ yellow
WH = White
VT = Violet
OG = Orange
BN = Brown
Voltage divider
HT-
BK
WH
BK
OG
YE
RD
GN
BK
BK
BK
Temperature sensor
HT transformer
Resistor for
mA measuring
(mA pos)
Stator
for the
rotation
BK
BU
RD
BN
BK
GN/YE
BK
BN
VT
BU
Filament transformer
Voltage
divider HT+
WH
K71
OG
