Spare parts and accessories
8.2 Optional accessories
Power Module PM240-2
118 Hardware Installation Manual, 12/2015, A5E33294624B AD
Output reactor - clearances
Mounting position
Clearances to other devices
Keep shaded areas free of any devices and components.
Figure 8-8 Minimum clearances of the output reactor to other devices, space-saving mounting
examples
