Siemens PM240-2

Technical data
7.5 Technical data, 690 V inverters
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
89
7.5.2
Specific technical data, 690 V inverters
The fuses listed in the following tables are examples of suitable fuses.
Additional components for branch protection:
Branch protection and short-circuit
strength according to UL and IEC
(https://support.industry.siemens.com/cs/ww/en/view/109479152)
Table 7- 24 PM240-2, IP20, FSD, 3 AC 500 V … 690 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PH21-4UL0
…1PH21-4AL0
…1PH22-0UL0
…1PH22 -0AL0
…1PH22-3UL0
…1PH22 -3AL0
LO base load power
LO base load input current
LO base load output current
11 kW
14 A
14 A
15 kW
18 A
19 A
18.5 kW
22 A
23 A
HO base load power
HO base load input current
HO base load output current
7.5 kW
11 A
11 A
11 kW
14 A
14 A
15 kW
20 A
19 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 815-0 / 25 A
20 A
3NE1 815-0 / 25 A
25 A
3NE1 803-0 / 35 A
30 A
Power loss without filter
Power loss with filter
0.32 kW
0.32 kW
0.41 kW
0.41 kW
0.48 kW
0.48 kW
Required cooling air flow
55 l/s
55 l/s
55 l/s
Weight without filter
Weight with filter
17 kg
18.5 kg
17 kg
18.5 kg
17 kg
18.5 kg
Table 7- 25 PM240-2, IP20, FSD, 3 AC 500 V … 690 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PH22-7UL0
…1PH22 -7AL0
…1PH23-5UL0
…1PH23 -5AL0
…1PH24-2UL0
…1PH24 -2AL0
LO base load power
LO base load input current
LO base load output current
22 kW
25 A
27A
30 kW
33 A
35 A
37 kW
40 A
42 A
HO base load power
HO base load input current
HO base load output current
18.5 kW
24 A
23 A
22 kW
28 A
27 A
30 kW
36 A
35 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 803-0 / 35 A
35 A
3NE1 817-0 / 50 A
45 A
3NE1 818-0 / 63 A
60 A
Power loss without filter
Power loss with filter
0.56 kW
0.56 kW
0.72 kW
0.73kW
0.88kW
0.88 kW
Required cooling air flow
55 l/s
55 l/s
55 l/s
Weight without filter
Weight with filter
17 kg
18.5 kg
17 kg
18.5 kg
17 kg
18.5 kg
