Connecting-up
5.1 Line and motor connection
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
37
Line and motor connection
Note:
Arrangement of the line and motor terminals (Page 45).
EMC-compliant installation (Page 50).
Permissible line supplies
Note
Restrictions for installation altitudes above 2000 m
Above an installation altitude of 2000
m, the permissible line supplies are restricted.
Restrictions for special ambient conditions (Page 92)
Note
Line requirement
The machine manufacturer must ensure that in operation the voltage drop between the
transforme
r input terminals and the inverter with rated values is less than 4%.
The inverter is designed for the following power distribution systems according to IEC 60364-
1 (2005).
