Siemens PM240-2

Technical data
7.4 Technical data, 400 V inverters
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
79
Dependent on the input voltage and output power 400 V inverters
7.4.2
Specific technical data, 400 V inverters
The fuses listed in the following tables are examples of suitable fuses.
Additional components for branch protection:
Branch protection and short-circuit
strength according to UL and IEC
(https://support.industry.siemens.com/cs/ww/en/view/109479152)
Table 7- 12 PM240-2, IP20, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE11-8UL1
…1PE11-8AL1
…1PE12-3UL1
…1PE12-3AL1
…1PE13-2UL1
…1PE13-2AL1
LO base load power
LO base load input current
LO base load output current
0.55 kW
2.3 A
1.7 A
0.75 kW
2.9 A
2.2 A
1.1 kW
4.1 A
3.1 A
HO base load power
HO base load input current
HO base load output current
0.37 kW
2.0 A
1.3 A
0.55 kW
2.6 A
1.7 A
0.75 kW
3.3 A
2.2 A
Fuse according to IEC
Fuse according to UL
3NA3 804 (4 A)
10 A Class J
3NA3 804 (4 A)
10 A Class J
3NA3 801 (6 A)
15 A Class J
Power loss
0.04 kW
0.04 kW
0.04 kW
Required cooling air flow
5 l/s
5 l/s
5 l/s
Weight without filter
Weight with filter
1.3 kg
1.5 kg
1.3 kg
1.5 kg
1.3 kg
1.5 kg
