Siemens PM240-2

Technical data
7.4 Technical data, 400 V inverters
Power Module PM240-2
80 Hardware Installation Manual, 12/2015, A5E33294624B AD
Table 7- 13 PM240-2, IP20, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE14-3UL1
…1PE14-3AL1
…1PE16-1UL1
…1PE16-1AL1
…1PE18-0UL1
…1PE18-0AL1
LO base load power
LO base load input current
LO base load output current
1.5 kW
5.5 A
4.1 A
2.2 kW
7.7 A
5.9 A
3.0 kW
10.1 A
7.7 A
HO base load power
HO base load input current
HO base load output current
1.1 kW
4.7 A
3.1 A
1.5 kW
6.1 A
4.1 A
2.2 kW
8.8 A
5.9 A
Fuse according to IEC
Fuse according to UL
3NA3 803 (10 A)
20 A Class J
3NA3 803 (10 A)
30 A Class J
3NA3 805 (16 A)
30 A Class J
Power loss
0.07 kW
0.1 kW
0.12 kW
Required cooling air flow
5 l/s
5 l/s
5 l/s
Weight without filter
Weight with filter
1.4 kg
1.6 kg
1.4 kg
1.6 kg
1.4 kg
1.6 kg
Table 7- 14 PM240-2, PT, frame sizes A, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3211…
6SL3211…
…1PE18-0UL1
…1PE18-0AL1
LO base load power
LO base load input current
LO base load output current
3.0 kW
10.1 A
7.7 A
HO base load power
HO base load input current
HO base load output current
2.2 kW
8.8 A
5.9 A
Fuse according to IEC
Fuse according to UL
3NA3 805 (16 A)
30 A Class J
Power loss without filter
0.12 kW
1)
Required cooling air flow
7 l/s
Weight without filter
Weight with filter
1.8 kg
2.0 kg
1) approx. 0.1 kW through the heatsink
