Siemens PM240-2

Technical data
7.4 Technical data, 400 V inverters
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
81
Table 7- 15 PM240-2, IP20, frame sizes B, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE21-1UL0
…1PE21-1AL0
…1PE21-4UL0
…1PE21-4AL0
…1PE21-8UL0
…1PE21-8AL0
LO base load power
LO base load input current
LO base load output current
4.0 kW
13.3 A
10.2 A
5.5 kW
17.2 A
13.2 A
7.5 kW
22.2 A
18.0 A
HO base load power
HO base load input current
HO base load output current
3.0 kW
11.6 A
7.7 A
4.0 kW
15.3 A
10.2 A
5.5 kW
19.8 A
13.2 A
Fuse according to IEC
Fuse according to UL
3NE 1814-0 (20 A)
35 A Class J
3NE 1815-0 (25 A)
35 A Class J
3NE 1803-0 (35 A)
35 A Class J
Power loss
0.11 kW
0.15 kW
0.2 kW
Required cooling air flow
9.2 l/s
9.2 l/s
9.2 l/s
Weight without filter
Weight with filter
2.9 kg
3.1 kg
2.9 kg
3.1 kg
3.0 kg
3.2 kg
Table 7- 16 PM240-2, PT, frame sizes B, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3211…
6SL3211…
...1PE21-8UL0
...1PE21-8AL0
LO base load power
LO base load input current
LO base load output current
7.5 kW
22.2 A
18.0 A
HO base load power
HO base load input current
HO base load output current
5.5 kW
19.8 A
13.7 A
Fuse according to IEC
Fuse according to UL
3NE 1803-0 (35 A)
35 A Class J
Power loss
0.2 kW
1)
Required cooling air flow
9.2 l/s
Weight without filter
Weight with filter
3.6 kg
3.9 kg
1) approx. 0.16 kW through the heatsink;
