Siemens PM240-2

Technical data
7.4 Technical data, 400 V inverters
Power Module PM240-2
82 Hardware Installation Manual, 12/2015, A5E33294624B AD
Table 7- 17 PM240-2, IP20, frame sizes C, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3210…
6SL3210…
…1PE22-7UL0
…1PE22-7AL0
…1PE23-3UL0
…1PE23-3AL0
LO base load power
LO base load input current
LO base load output current
11.0 kW
32.6 A
26.0 A
15.0 kW
39.9 A
32.0 A
HO base load power
HO base load input current
HO base load output current
7.5 kW
27.0 A
18.0 A
11.0 kW
36.0 A
26.0 A
Fuse according to IEC
Fuse according to UL
3NE 1817-0 (50 A)
50 A Class J
3NE 1817-0 (50 A)
50 A Class J
Power loss
0.3 kW
0.37 kW
Required cooling air flow
18.5 l/s
18.5 l/s
Weight without filter
Weight with filter
4.7 kg
5.3 kg
4.8 kg
5.4 kg
Table 7- 18 PM240-2, PT, frame sizes C, 3-phase 380 … 480 VAC
Article no. - without filter
Article no. - with filter
6SL3211…
6SL3211…
...1PE23-3UL0
...1PE23-3AL0
LO base load power
LO base load input current
LO base load output current
15.0 kW
39.9 A
32.0 A
HO base load power
HO base load input current
HO base load output current
11.0 kW
36.0 A
26.0 A
Fuse according to IEC
Fuse according to UL
3NE 1817-0 (50 A)
50 A Class J
Power loss
0.37 kW
1)
Required cooling air flow
18.5 l/s
Weight without filter
Weight with filter
5.8 kg
6.3 kg
1) approx. 0.3 kW through the heatsink;
