Siemens PM240-2

Technical data
7.4 Technical data, 400 V inverters
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
83
Table 7- 19 PM240-2, IP20, FSD, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE23-8UL0
…1PE23-8AL0
…1PE24-5UL0
…1PE24-5AL0
…1PE26-0UL0
…1PE26-0AL0
LO base load power
LO base load input current
LO base load output current
18.5 kW
36 A
38 A
22 kW
42 A
45 A
30 kW
57 A
60 A
HO base load power
HO base load input current
HO base load output current
15 kW
33 A
32 A
18.5 kW
38 A
38 A
22 kW
47 A
45 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 818-0 / 63 A
60 A
3NE1 820-0 / 80 A
70 A
3NE1 021-0 / 100A
90 A
Power loss without filter
Power loss with filter
0.55 kW
0.56 kW
0.68 kW
0.68 kW
0.76 kW
0.77 kW
Required cooling air flow
55 l/s
55 l/s
55 l/s
Weight without filter
Weight with filter
16 kg
17.5 kg
16 kg
17.5 kg
17 kg
18.5 kg
Table 7- 20 PM240-2, IP20, FSD, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE27-5UL0
…1PE27-5AL0
LO base load power
LO base load input current
LO base load output current
37 kW
70 A
75 A
HO base load power
HO base load input current
HO base load output current
30 kW
62 A
60 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 021-0 / 100 A
100 A
Power loss without filter
Power loss with filter
1.01 kW
1.02 kW
Required cooling air flow
55 l/s
Weight without filter
Weight with filter
17 kg
18.5 kg
