Siemens PM240-2

Technical data
7.4 Technical data, 400 V inverters
Power Module PM240-2
84 Hardware Installation Manual, 12/2015, A5E33294624B AD
Table 7- 21 PM240-2, IP20, FSE, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE28-8UL0
…1PE28-8AL0
…1PE31-1UL0
…1PE31-1AL0
LO base load power
LO base load input current
LO base load output current
45 kW
86 A
90 A
55 kW
104 A
110 A
HO base load power
HO base load input current
HO base load output current
37 kW
78 A
75 A
45 kW
94 A
90 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 022-0 / 125A
125 A
3NE1 224-0 / 160A
150 A
Power losses without filter
Power losses with filter
1.19 kW
1.2 kW
1.54 kW
1.55 kW
Required cooling air flow
83 l/s
83 l/s
Weight without filter
Weight with filter
26kg
28 kg
26 kg
28 kg
Table 7- 22 PM240-2, IP20, FSF, 3 AC 380 V … 480 V
Article No. - without filter
Article No. - with filter
6SL3210-…
6SL3210-…
…1PE31-5UL0
…1PE31-5AL0
…1PE31-8UL0
…1PE31-8AL0
…1PE32-1UL0
…1PE32-1AL0
LO base load power
LO base load input current
LO base load output current
75 kW
140 A
145 A
90 kW
172 A
178 A
110 kW
198 A
205 A
HO base load power
HO base load input current
HO base load output current
55 kW
117 A
110 A
75 kW
154
145 A
90 kW
189 A
178 A
Siemens fuse according to IEC/UL
Fuse according to IEC/UL, Class J
3NE1 225-0 / 200 A
200 A
3NE1 227-0 / 250 A
250 A
3NE1 230-0 / 315 A
300 A
Power loss without filter
Power loss with filter
1.95 kW
1.97 kW
2.54 kW
2.56 kW
2.36 kW
2.38 kW
Required cooling air flow
153 l/s
153 l/s
153 l/s
Weight without filter
Weight with filter
57 kg
63 kg
57 kg
63 kg
61 kg
65 kg
