Siemens PM240-2

Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
19
Introduction
3
Overview
The PM240-2 Power Modules belong to the modular family of SINAMICS G120 inverters. A
G120 inverter comprising Control Unit and Power Module.
Depending on the power rating in frame sizes FSA … FSF, the following Power Module
versions are supplied:
•
1 AC 200 V
0.55
kW … 4 kW
for line voltages from 1
AC 200 V … 240 V
•
3 AC 200 V
0.55
kW … 55 kW
for line voltages from 3
AC 200 V … 240 V
•
3 AC 400 V
0.55
kW … 132 kW
for line voltages from 3
AC 380 V … 480 V
•
3 AC 690 V
11
kW … 132 kW
for line voltages from 3
AC 500 V … 690 V
You can operate the Power Modules with one of the following Control Units.
● CU230P-2
● CU240B-2
● CU240E-2
● CU250S-2
For Power Modules FSA … FSC, you require a Control Unit with firmware version V4.4 or
higher.
For Power Modules FSD … FSF, you require a Control Unit with firmware version V4.7 HF8
or higher.
Note
Commissioning the inverter
You must first commission t
he inverter before you can use it. Commissioning is described in
the operating instructions of the relevant Control Unit. Please refer to the List Manual of the
Control Unit for additional information on the inverter.
Manuals for your inverter (Page 123)
STO independent of the Control Unit
Using the PM240-2 Power Modules, frame sizes FSD, FSE and FSF, you can implement the
"Safe Torque Off" safety function (STO), corresponding to PL e according to EN 13849-1
and SIL 3 according to IEC61508.
STO via Power Module terminals (Page 49).
