Siemens PM240-2

Spare parts and accessories
8.2 Optional accessories
Power Module PM240-2
Hardware Installation Manual, 12/2015, A5E33294624B AD
121
Table 8- 9 Technical data of the output reactors
Article number
6SL3202-0AE16-1CA0
6SL3202-0AE18-8CA0
6SL3202-0AE21-8CA0
6SL3202-0AE23-8CA0
Inductance
2.5 mH
1.3 mH
0.54 mH
0.26 mH
Degree of
protection
IP20 IP20 IP20 IP20
Weight
3.4 kg
3.9 kg
10.1 kg
11.2 kg
Table 8- 10 Assignment table
Output reactor
400 V Power Modules
200 V Power Modules
6SL3202-0AE16-1CA0 6SL3210-1PE11-8☐L1
6SL3210-1PE12-3☐L1
6SL3210-1PE13-2☐L1
6SL3210-1PE14-3☐L1
6SL3210-1PE16-1☐L1
6SL3210-1PB13-0☐L0
6SL321☐-1PB13-8☐L0
6SL3210-1PB15-5☐L0
6SL3202-0AE18-8CA0
6SL321☐-1PE18-0UL1
6SL3210-1PB17-4☐L0
6SL3202-0AE21-8CA0 6SL3210-1PE21-1☐L0
6SL3210-1PE21-4☐L0
6SL321☐-1PE21-8☐L0
6SL321☐-1PB21-0☐L0
6SL3210-1PB21-4☐L0
6SL321☐-1PB21-8☐L0
6SL3202-0AE23-8CA0 6SL3210-1PE22-7☐UL0
6SL321☐-1PE23-3☐L0
6SL321☐-1PC22-2☐L0
6SL3210-1PC22-8☐L0
