Siemens PM240-2

Installing/mounting
4.3 Mounting the Power Modules
Power Module PM240-2
28 Hardware Installation Manual, 12/2015, A5E33294624B AD
Depth with Control Unit and Operator Panel (mm)
CU230P-2
CU240B/E-2
CU250S-2
FSA … FSC
• With Control Unit:
• With Control Unit and blanking cover / BOP-2:
• With Control Unit and IOP:
+ 59
+ 70
+ 81
+ 41
+ 52
+ 63
+ 62
+ 73
+ 84
FSD … FSF
• With Control Unit:
• With Control Unit and blanking cover / BOP-2:
• With Control Unit and IOP:
+ 15.5
+ 26.5
+ 37.5
+ 0
+ 8.5
+ 19.5
+ 18.5
+ 29.5
+ 40.5
