Connecting-up
5.1 Line and motor connection
Power Module PM240-2
48 Hardware Installation Manual, 12/2015, A5E33294624B AD
Establishing connections
Procedure
Proceed as follows to establish the connections:
1. Ensure that the device is in a no-voltage condition and the DC link is discharged.
2. When available, remove the covers.
3. Establish the connections.
4. Reattach the covers before you connect the power.
You have established the connections.
