Connecting Resistance Thermometers in 4-Wire Technology

2.7.4 SM-0572

The SM-0572 submodule (analog output extension 2x ±20 mA/±1 V/±10 V) provides two ana-

log outputs.

Pt100 / Ni100

SM-0571

I/O 1

IN IREF0+

IN V0+

IN V0-

IN IREF0-

IN IREF1+

IN V1+

IN V1-

IN IREF1-

I/O 3

I/O 2

I/O 0

I/O 7

I/O 5

I/O 4

I/O 6

SICAM RTUs

carrier module

internal

interface

SM-0572

2 analog outputs
