Siemens SICAM AK 3 User Manual

Engineering via SICAM TOOLBOX II
194 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
4.1.8.4 Telecontrol Function
4.1.8.4.1 System-technical Parameter
You can initiate the documentation of the system-technical configuration in the menu System
technique , via the context menu of an automation unit or of a specific system element.
The output takes place as a spreadsheet, optionally as preview on the screen or to a printer.
4.1.8.4.2 Process-Technical Settings
You can initiate the documentation of the process-technical settings in the tree of the menu
Edit image , via the context menu of a selected hierarchical level.
The output takes place as a spreadsheet, optionally as preview on the screen or to a printer.
4.1.9 Commissioning an Test
For commissioning and test of the projected settings the following functions are available
(online):
• Load engineering data
• Parameter comparison
• Test functions
• Diagnosis (see section 5.3, Diagnosis )
For these functions the engineering PC must be connected with the target system (see 3.2,
Connect Engineering PC with a Target System).
4.1.9.1 Loading Engineering Data
The loading of the parameters of a process-technical plant from the PC into the target system
takes place with the tool "Load Parameters". You can launch it from the "OPM II" via the menu
Target systems | SICAM RTUs | Parameter loader , or directly via the start menu of
your PC.
With the tool "Parameter Loader" you can add and select automation units, and initiate the
loading via the menu Load | Selected AUs .
