System Components
154 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
2.7.4.3 External Circuitry
Current Output
Voltage Output
SICAM RTUs
OUT V0+
OUT V0-
OUT V1+
OUT V1-
SM-0572
(500
max)
(500
max)
R
L
R
L
I/O 2
I/O 3
I/O 6
I/O 7
SICAM RTUs
OUT V0+
OUT V0-
OUT V1+
OUT V1-
I/O 2
R
L
R
L
(1 k
min)
(1 k
min)
I/O 3
I/O 6
I/O 7
SM-0572
