System Components
SICAM RTUs, SICAM AK 3 User Manual 89
DC2-028-2.03, Edition 07.2016
2.1.1.3 Pin Assignment
The power supply connector X1 is assigned according to the following table.
PS-2630 PS-2632
Pin Signal Pin Signal
1 + 1 L/+
2 - 2 N/-
3 PE 3 PE
The abbreviations have the following meaning:
+ ................................ Power Supply + (24 to 60 VDC)
- ................................. Power Supply- (24 to 60 VDC)
L/+ ............................. Power Supply+ (110 to 220 VDC, 230 VAC)
N/-.............................. Power Supply- (110 to 220 VDC, 230 VAC)
PE.............................. Protective earth
