Siemens SICAM AK 3 User Manual

System Components
164 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
2.8.2.4 Configuration (Examples)
16 Peripheral Elements, electrically and optically connected
SICAM AK
PS-263x CP-2016 D I-211 0 DI -211 0 CP-2019 DO-2210 AI-2301 AI-2300
SICAM 1703 SICAM 1703
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
. . . .
..........
..........
Ax 1703 peripheral bus (electrical)
16 Mbps
patch cable, length up to 3 m
Ax 1703 peripheral bus
(electrical)
16 Mbps
USB cable,
length up to 3 m
Ax 1703 peripheral bus (optical)
16 Mbps, optical fibre,
length up to 200 m
max. 8 I/O-modules
1 . . . 4
CM-0842
CM-0843
1 . . . 4
PS-663x
PS-663x
PE-6410
PE-6411,12
9
1
15
7
16
8
