Siemens SICAM AK 3 User Manual

Installation
SICAM RTUs, SICAM AK 3 User Manual 25
DC2-028-2.03, Edition 07.2016
1.2.2.3 CM-2848 – Rear Panel Installation
280
258
266
430
30
Space needed for cabling
Cabinet rear panel
3HU
SICAM AK
PS-263x
SICAM AK
PS-263x
DI -2 110CP-2016 CP-2019 AI- 23 01 AI - 23 00DO-2210DI -2 110 D I- 211 0 D I -2 110 AI-2300
DI -2 110
DI - 211 0
DI - 2110
CP-2019
AI-2301
D O- 22 10
483
266
603
190
3
5
465
435
minimum free space
3HU
