Installation
54 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
1.4.5.1.5 Dial-Up Traffic GSM
Accessories see SICAM AK 3 System Description.
CP-2016
CP-2019
X0
X1
X2
X3
X0
X1
X2
X3
Power
supply
CP-2016 with
SM-2551)
SM-0551 on SM-2558
(or CP-2016 with
CP-2019 with SM-2551
(or CP-2019 with SM-0551 on SM-2558)
GSM Modem
max. 25 m
8...30 VDC (Cinterion MC52i)
