Engineering via SICAM TOOLBOX II
192 SICAM RTUs, SICAM AK 3 User Manual
Edition 07.2016, DC2-028-2.03
4.1.5.4 Decentralized Archiving (DEAR)
The Decentralized Archive serves for the archiving of events during a communication fault.
Here all the data points used in an automation unit can be acquired.
You can configure the archive in the system technique of the "OPM II" (parameter group De-
centralized archiving of the respective automation unit). In the images you can define
the process-technical settings of the data points to be acquired. During operation, these data
points are archived chronologically upon status change. This applies for all commands and bi-
nary information items of the send and receive direction.
You find the detailed information on the settings in the manual SICAM RTUs Common Func-
tions System and Basic System Elements, chapter "Telecontrol", section "Decentralized Ar-
chiving".
4.1.6 Transform Parameters
Before loading into the target system, the process-technical parameters of the plant must be
transformed. This can be carried out with the tool "OPM II" through selection of the menu
Destination systems | SICAM RTUs… | SICAM RTUs Transformer .
System-technical parameters are automatically transformed when saved.
You find the details thereto in the SICAM TOOLBOX II Online Help, chapter "OPM II", section
"Transform and Load", "SICAM RTUs".
4.1.7 Import, Export and Backup of Engineering Data
The tool "Data Distribution Center" enables the importing and exporting of parameters, as well
as the creation of backup files.
You find the details thereto in the SICAM TOOLBOX II Online Help, chapter "Data Distribution
Center".
4.1.8 Documentation
With the tool "OPM II" you can generate and print the documentation of the engineering data:
• Hardware Configuration
• Assembly Technique
• Interface to Elcad
• Telecontrol Function
─ System-technical configuration
─ Process-technical settings
You find the details thereto in the SICAM TOOLBOX II Online Help, chapter "OPM II", section
"System Technique", section "Documentation".
