Siemens SICAM AK 3 User Manual

Installation
SICAM RTUs, SICAM AK 3 User Manual 75
DC2-028-2.03, Edition 07.2016
• Then swing the peripheral cable forwards up to the stop ‚, Thereby the hook of the grip
flap must be guided through the unlocking lever.
• Now push the peripheral cable upwards. Thereby grip flap and seating frame are finally
fixed together ƒ
2
Hook
Unlocking lever
3
