Setting up and connecting the device
3.2 Setting up the device
MD-34A
34 Operating Instructions, 08/2023, A5E52427535-AA
Removing the rechargeable battery
For insertion of cards, an extended period of non-use, or replacement, remove the battery as
follows:
1. Turn the device over so that it is lying on a flat surface.
2. Push the battery lock to the "Unlocked" position.
3. Press and hold down the battery lock while lifting the battery out of the battery
compartment.
Inserting the rechargeable battery
1. Push the battery lock to the "Unlocked" position.
2. Insert the battery, contact pins first, into the battery slot and press it down.
When the battery is inserted, it should sit flush with the battery compartment.
3. Push the battery lock to the "Locked" position.
