Siemens SIMATIC IPC MD-34A User Manual

MD-34A
Operating Instructions, 08/2023, A5E52427535-AA
81
Technical data
8
8.1 General technical specifications
Device function
Data
Value
Display
Size
10.1 inch
Resolution
1920 × 1200 (1280 × 800)
Brightness
800 nits (350 nits)
Contrast ratio
800:1 (typ.)
Viewing angle
85/85/85/85
Touch
Projected capacitive multi-touch
Bonding structure
Multi-layer bonding structure for read-
ability in sunlight
Readability
Anti-glare coating
System specification
Processor
Intel Core i5-1135G7 / 2.4 GHz (Turbo
Boost up to 4.2 GHz, optional)
Main memory 8 GB DDR4 SDRAM (optional up to 32
GB)
Mass storage
512 GB (256 GB) SSD, additional
memory capacity on microSD card
Operating system
Windows 10 IoT Enterprise (64-bit)
WLAN
802.11 a/b/g/n/ac/ax
Bluetooth
Supported V 5.3
GNSS
GPS (optional), GLONASS
WWAN (optional)
4G / LTE
Readers
Barcode (optional)
RFID (optional)
HF RFID
Camera
Front camera
Front camera (2 MP)
Rear camera
Rear camera (8 MP) with autofocus and
LED light
Mechanical system
Dimensions
266 × 187 × 20.4 mm
Weight
1.1 kg
Cooling system
Fan
I/O connections USB connection 1 × USB 3.0 (Type A), 1 × USB 3.0 (Type
C)
Video
1 × Micro HDMI (optional)
Audio
1 × Audio combo jack 3.5 mm (Mic in or
Line out)
Integrated dual-mic microphone
Single speaker
SD card tray
1 × microSD tray
SIM card tray (optional)
1 × SIM card tray
Status display
2 × LED display for electricity supply
and battery
