Technical data
8.5 Dimension drawing
MD-34A
84 Operating Instructions, 08/2023, A5E52427535-AA
Immunity to RF interference
• 10 V/m; 80 up to 2700 MHz
80% AM to IEC 61000-4-3
• 3 V/m; 2.7 to 6 GHz
80% AM to IEC 61000-4-3
• 10 V; 10 kHz up to 80 MHz
80% AM to IEC 61000-4-6
Immunity to magnetic fields
100 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8)
8.5 Dimension drawing
Figure 8-1 All dimensions in mm
