Setting up and connecting the device
3.2 Setting up the device
MD-34A
Operating Instructions, 08/2023, A5E52427535-AA
35
3.2.2 Inserting the SIM card
Requirement
1. The battery of the tablet is removed.
2. Flip the tablet over and set it down on a soft surface with the rear side facing up.
Procedure
The device supports data connections conforming to the 4G/LTE wireless standard and
accommodates a nano-SIM card.
1. Briefly press against the SIM card tray to release it, and then pull it out all the way.
2. Insert the SIM card from above into the SIM card tray.
– Do not touch the chip contacts of the SIM card.
– Make sure that the chip contacts are facing downward.
– The notch on the SIM card must be at the top left next to the notch in the card tray.
3. Slide the SIM card tray back in.
4. Insert the SD card or reinsert the battery.
