Siemens SIMATIC IPC MD-34A User Manual

Firmware/BIOS description
7.2 Configure firmware
MD-34A
Operating Instructions, 08/2023, A5E52427535-AA
77
Firmware setting Value Setting in deliv-
ery state
Meaning
UEFI: IPv6
HTTP: IPv6
HTTP and PXE:
IPv6
UEFI: IPv4/IPv6
HTTP: IPv4/IPv6
HTTP and PXE:
IPv4/IPv6
x
Timeout
0 - 10
2
Delay time in seconds during booting so
that the user has time to press the hot-
key to open the firmware selection
menu.
Automatic Failo-
ver
Enabled
x
If it fails to boot the default device, it
will try to boot next device.
Disabled
If it fails to boot the default device, a
warning messages will appear and then
it will go into firmware UI.
Boot Type Order
Use F5 or F6 key on the connected key-
board to change boot type order.
HTTP Boot Con-
figuration
Configure boot parameter by MAC Ad-
dress via IPv4 or IPv6 protocol.
1
: This option shows only when "Network Stack" = Enabled.
Calling "Boot Type Order"
Select: "Setup Utility (Page 71)" > "Boot" > "Boot Type Order".
Firmware setting Value Setting in deliv-
ery state
Meaning
Hard Disk Drive
Windows Boot
Manager
x
Change Hard Disk Driver boot order.
USB
BEV
EFI HTTP[IPv6]
x
Change BEV boot order.
EFI HTTP[IPv4]
x
EFI PXE 0 for IPv6
x
EFI PXE 0 for IPv4
x
Others
Calling "HTTP Boot Configuration"
Select: "Setup Utility (Page 71)" > "Boot" > "HTTP Boot Configuration" > "XXX (Mac address of
the device)".
Firmware setting Value Setting in deliv-
ery state
Meaning
Internet Protocol
IPv4
x
Select the version of Internet Protocol.
IPv6
