Siemens SIMATIC MV540 H User Manual

SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
103
Process interfacing via an automation system (PLC,
PC)
9
You can operate the optical reader with either the WBM or an automation system. Using an
automation system (e.g. S7 controller), you can control the optical reader and view read
results and verification results.
Note
Controlling the readers via an automation system
Note that when the WBM is active, you can only control the readers via an automation
system (e.g. Saving and changing programs), if the "Take control" check box in the
"Security" tab is disabled for the current user in the "Options" menu of the WBM.
Table 9- 1 Overview: Compatible communication modules, controllers and program blocks
Ident systems and MV
interface
Compatible program blocks in conjunction with ...
Ident profile
with S7-300/400/
1200/1500
FB 45
with S7-300/-400
1)
FB 79
with S7-300/-400
Without a dedicated
FB
SIMATIC MV500
via ASM 456
✓ ✓ -- --
CM interface
SIMATIC MV500
via ASM 475
-- ✓ -- --
CM interface
SIMATIC MV500
via RF120C
✓
2)
-- -- --
CM interface
SIMATIC MV500
via RF170C
✓ ✓ -- --
CM interface
SIMATIC MV500
via RF180C
✓ ✓ -- --
CM interface
SIMATIC MV500
via RFID 181EIP
-- -- -- ✓
3)
CM interface
