Technical data
11.3 Technical specifications built-in ring light
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
199
11.3
Technical specifications built-in ring light
Table 11- 3 Technical specifications of the built-in ring light for SIMATIC MV500
6GF3540-8DAxx
Product type designation
Built-in ring light for SIMATIC MV500
Optical data
Lighting distance (max.)
0.8 m
Light color / wavelength
(relative luminosity 0.2 ... 1.0)
8DA13: Red / 618 nm
Flash mode
Duty cycle 8%
Max. exposure time 10 ms
Permitted ambient conditions
Ambient temperature
During operation 0 … +50 °C
During transportation and storage -20 … +70 °C
Relative humidity (max.)
95%
Design, dimensions and weight
Dimensions ( × H)
54 × 54 mm
Weight
20 g
Standards, specifications, approvals
MTBF
8DA13: 152 years
