Network and system integration
4.5 System setup via the RS-232 interface
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
57
System characteristics
The result output of the optical reader takes place via the Ethernet interface.
The optical reader can be triggered via either:
Digital I/O
TCP/IP
The built-in auto-trigger function
A PC/programming device is connected via Ethernet and a switch to allow adjustment of
the device.
4.5
System setup via the RS-232 interface
Optical sensor or light barrier (for trigger signal)
Object with code
Figure 4-4 Example: System configuration via the RS232 interface
