Service and maintenance
10.1 Error and diagnostics messages
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
181
10.1.4
Read and verification error messages
If a read error or verification error occurs, the following error codes and error messages are
output. You can find additional information in the section "Overall result" of the online help.
Note
The causes of error 4700 to 4722 are also output in the verification report if there is a
verification error
All verification grades are output in the report as "E". The verification values correspond to
the error code.
Note
Evaluating verification errors as read errors
If th
e "Evaluate quality 'Poor' as "N_OK" check box has been selected in the decoding
settings, a verification error will also be evaluated as "N_OK".
Table 10- 3 Read/verification error messages
Error code
(%c)
Error message
(%s)
Description
0001
No 1D/2D code found in step n
No code was found in step #n.
0002 Cycletime too short The processing was not completed within the cycle
time limit.
0003
Trigger too fast
The processing was interrupted by a trigger signal.
0004 Non ECC200 Code in step n A data matrix code was found in step #n that does not
correspond to ECC200.
Note:
The check for ECC200 is performed only in adjust-
ment mode and during "Save program".
0005 Step n: Structured Append DMC not supported In step #n, a "Structured Append" DMC type was
found. This DMC type is not supported.
0006 Step n: Reader Programming DMC not supported In step #n, a "Reader Programming Code" DMC type
was found. This DMC type is not supported.
0007 Step n: QR ECI encoding not supported In step #n, a QR code with "ECI encoding" was found.
This QR type is not supported.
0008 Step n: QR Byte encoding not supported In step #n, a QR code with "Byte encoding" was
found. This QR type is not supported.
0009 Step n: QR Kanji encoding not supported In step #n, a QR code with "Kanji encoding" was
found. This QR type is not supported.
0010 Step n: Structured Append QR code not support-
ed
In step #n, a "Structured Append" QR type was found.
This QR type is not supported.
0011 Step n: QR FNC1 encoding not supported In step #n, a QR code with "FNC1 encoding" was
found. This QR type is not supported.
0012 Code quality is poor in step n A code with "poor" quality evaluation was read in
step #n during verification.
