Process interfacing via an automation system (PLC, PC)
9.9 Example programs
SIMATIC MV500
170 Operating Instructions, 06/2018, C79000-G8976-C494-01
Adding program change
Specify the number of the required program in memory byte MB200. The program change
runs automatically. The correct order of the commands is adhered to. The FB changes to the
program specified in the "PARAM1" parameter.
CAUTION
Avoiding undefined plant states
To avoid undefined plant states, you should only change programs when the plant is in
manual mode or is not in operation.
Startup OB OB100
In OB100, you set the RESET input of FB 79 to initialize the FB. This input is reset by the FB
79 call.
Bits of the control and status bytes used
You must edit the following control and status bytes in addition to the FB 79 call in your
program:
Table 9- 63 Control and status bytes for FB 79 call
Bit
Byte
Signal
Description
A x.6
Control byte
TRG
Processing is started with a positive edge.
A x.7
Control byte
RES
Reset sensor error
E x.0 Status byte IN_OP 0: Error or startup
1: Sensor is functional
E x.2 Status byte RDY 1: Sensor is in "RUN" mode, i.e. it is ready to pro-
cess codes.
You can use this signal to enable the feed of work
pieces.
9.9.2
Archiving of images and diagnostic information on a PC
You can find the program described in this section on the Web pages of Siemens Online
Product Support (https://support.industry.siemens.com/cs/ww/en/ps/15147/ae
).
Using the "MMIDiagnosticsGUI.exe" file, you archive diagnostic data records in the form of
CSV files and diagnostics images as bitmaps on a PC. A text file containing bitmap details is
sent along with the diagnostics images.
