Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
217
13.3.7
Mounting/calibration boards
Table 13- 17 Mounting plates for SIMATIC MV500
Mounting plate
Description
Article number
Mounting plate
• W × H × D: 80 × 80 × 60 mm
• Material: Stainless steel
• Thickness: 4 mm
• Mounting: Metric thread, photo thread
(1/4", 2 x center)
6GF3440-8CA
Support system, tri-plate
• W × H × D: 165 × 175 × 65 mm
• Material: Stainless steel
• Thickness: 4 mm
• For mounting SIMATIC MV500 via
mounting plate
6GF9002-7AD
Table 13- 18 Calibration card for SIMATIC MV500
Calibration card
Description
Article number
Calibration card
1)
• W × H × D: 45 × 70 × 75 mm
6GF3440-8CE
1)
The calibration card is required for operation of the optical reader with verification functionality. The
calibration card is included with the SIMATIC MV500 Veri-Genius license (delivery stage 2).
