Appendix
A.3 Alternative user interfaces
SIMATIC MV500
Operating Instructions, 06/2018, C79000-G8976-C494-01
231
Overview of available URLs
Using the following URLs, you can open the pages described above in the language of your
choice. Example of a URL: http://<IP address of optical reader>/peeklive.html
Overview of the HTML pages for monitoring the optical reader
Table A- 4 English, Chinese, German
Page
English
Chinese
German
Homepage
1)
index_en.html
index_zh.html
index_de.html
Setup (user interface)
1)
adj_en.cgi adj_zh.cgi adj_de.cgi
Diagnostics recordings
2)
diagrecs.cgi?rg=65535
diagrecs.cgi?rg=65535
diagrecs.cgi?rg=65535
Diagnostics images
2)
diagimgs.cgi?tn=1
diagimgs.cgi?tn=1
diagimgs.cgi?tn=1
Extended diagnostics images
2)
ediagimghtml.cgi ediagimghtml.cgi ediagimghtml.cgi
Live Image with links
peeklive.html
peeklive_zh.html
peeklive_de.html
Live image without links
2)
epeeklive.html
epeeklive.html
epeeklive.html
Last image
2)
live.cgi?d=0
(d=0: not-down sampled,
d=1 down sampled)
live.cgi?d=0
(d=0: not-down sampled,
d=1 down sampled)
live.cgi?d=0
(d=0: not-down sampled,
d=1 down sampled)
Monitoring
2)
drawresults.cgi
drawresults.cgi
drawresults.cgi
Verification report
cgui/verifireport_en.html
cgui/verifireport_en.html
cgui/verifireport_de.html
1)
The language in which the HTML page is displayed is independent of the language abbreviation used. The HTML pages
are always displayed in the language set in the WBM.
2)
These HTML pages are displayed only in English.
A.3.3
Use of saved images
The optical reader user interface provides the option of using the images stored on the PC
for the purpose of parameter assignment or for trial mode.
The resolution and format of the images must match the program selected at this time.
Possible image sources are, for example, the diagnostic images saved via the user interface
or images archived using diagnostics transfer (MMI).
An HTML5 capable web browser is required to use the function, for example, Microsoft
Internet Explorer version 10 or higher, Mozilla Firefox version 28 or higher or Google
Chrome version 38 or higher.
