Service and maintenance
10.1 Error and diagnostics messages
SIMATIC MV500
184 Operating Instructions, 06/2018, C79000-G8976-C494-01
Error code
(%c)
Error message
(%s)
Description
4721 Verification failed in step n: Cell size is smaller
than the specified Min.X Dim.
During verification, a cell size was measured that is
less than the minimum X-dimension setting (only for
verification according to ISO/IEC 29158).
4722 Verification failed in step n: Cell size is larger than
the specified Max.X Dim.
During verification, a cell size was measured that is
greater than the maximum X-dimension setting (only
for verification according to ISO/IEC 29158).
5000 Not enough resources to process step n Step #n could not be executed due to a lack of re-
sources (memory).
5001
No objects found in step n
Locator: No objects were found in step #n.
10.1.5
Filter error messages
If a filter error occurs, the following error messages are output. You can find additional
information in the section "Overall result" of the online help.
Table 10- 4 Filter error messages
Error message
(%s)
For filter mode only
Description
Symbol does not use GS1-
encoding
GS1 The code read does not begin with the GS1
start symbol "]d2".
"[Number]" is no valid GS1 Ap-
plication Identifier
GS1 The string selected in the "Filter ID" box
contains an invalid application identifier tag.
GS1 Application Identifier
"[Number]" not found in symbol
content
GS1 An application identifier specified in the
"Filter ID" box was not found in the read
code.
Symbol content shorter than
given "start position"
Position The read code is shorter than the selected
"Start position"
ID or separator not found in
symbol content
ID An ID (field: "Filter ID") or a separator
character (field: "Separators") was not
found in the read code.
