Siemens SIMATIC MV540 H - Built-In Ring Lights

Scope of delivery and ordering data
13.3 Accessories
SIMATIC MV500
210 Operating Instructions, 06/2018, C79000-G8976-C494-01
Table 13- 3 EF mini-lens for SIMATIC MV500
Lens
Description
Article number
EF mini-lens 25 mm,
1:1.4 EDMUND
• Adjustable focal distance
• Aperture and focus
• Dimensions (∅ × L): 31 × 56 mm
6GF3540-8EA03-
0LL0
13.3.2
Built-in ring lights
Note
Achievement of IP67 protection
In order to achieve IP67 degree of protection, one of the protective lens barrels is required in
addition:
Without a protective lens barrel, the camera only achieves IP20 degree of protection.
Note
Compatibility of the built-in ring lights for SIMATIC MV440
Note that SIMATIC MV440 built
-in ring lights are compatible with SIMATIC MV500 optical
readers. However, using the MV440 built
-in ring lights on MV500 does not support the micro
SD card
and E-focus function.
Table 13- 4 Built-in ring lights for SIMATIC MV500
Built-in ring light
Description
Article number
Built-in ring light (Multi, red) for
SIMATIC MV500
• Light source: LED red
(618 nm)
• Lighting distance up to 3.0 m
• Including attachment with polarization
filter and reflectors
• Including anti-glare attachment
6GF3540-8DA13
